BluePrint Engines GM Big Block Compatible 502 c.i. Pro-Series Engine - Short Block
Part# PS502
BluePrint Engines GM Big Block Compatible 502 c.i. Pro-Series Engine - Short Block
- Made in USA
- GM Compatible
$6,999.00
Free Shipping
Buy with confidence. Warranty terms are noted on your invoice,
delivery is included in the lower 48 states, and our specialists are a phone call away
through installation and beyond.
BluePrint Engines GM Big Block Compatible 502 c.i. Pro-Series Engine - 627 Horsepower - Short Block
Specifications
| Compression Ratio | 10.5:1 with 118cc heads and .039'' crushed gasket |
|---|---|
| Block Description | 4 Bolt Splayed Cast Caps, 1 PC Rear Seal Block |
| Rear Main Seal Style | 1 PC |
| Rotating Assembly | Forged Crank - 4.000" Storke - 6.385" Connecting Rods |
| Pistons | Forged 4032, 13cc Dome, 1.270’'CH, 1.5/1.5/3mm RINGS |
| Engine Balance | Internally Balanced Front and Rear |
| Country of origin | USA |
| Shipping weight | 280 lb |
| Shipping size | 26 x 23.5 x 22.5 in |
